Harman Kardon Onyx Studio 9

Features and Benefits
Superior sound performance with a wider soundstage Get lost in your music with our new Constant Sound Field technology.The three-channel system, featuring a dedicated center channel for crystal-clear vocals surrounded by two specially designed tweeters, delivers a wider soundstage. This immersive experience brings your favorite songs to life all around you.

Iconic design
The Harman Kardon Onyx Studio 9 has a clean, circular design that looks great everywhere. The integrated aluminum frame doubles as a sturdy handle and stand, the soft but durable fabric looks sharp and feels nice,
while the easy-to-use silicon buttons on top give you quick control.

Bluetooth music streaming
The Harman Kardon Onyx Studio 9 pairs seamlessly with up to two mobile devices simultaneously. Take turns sharing playlists and music, all in enhanced, dynamic sound.

Multi-speaker connection by Auracast™
The Onyx Studio 9 features multi-speaker connection via Auracast. By pressing the Auracast button on the speaker or using the Harman Kardon ONE app, you can connect two or more Harman Kardon speakers (or
compatible speakers from other brands) to transform any space into an
exciting musical environment. Effortlessly synchronize as many speakers
as you want and create an immersive audio experience.

Built-in battery
With its rechargeable built-in battery, you can enjoy the Harman Kardon Onyx Studio 9 anywhere in your home, and easily transport it from one room to another for up to 8 hours of playtime.

Self-Tuning
Enjoy perfect sounds wherever you take the music. When you power on, the Onyx Studio 9 automatically calibrates to its environment, ensuring the best sound possible no matter where you set it down.Boost stereo sound with two speakers.Quickly and easily turn up the celebration with a wider, more detailed
soundstage by pairing two Onyx Studio 9 speakers together, wirelessly.

USB Charging port
Never worry about your mobile device running out of juice while you’re streaming your favorite audiobook. The USB charging port means you and your device will always be ready for anything.

Harman Kardon One App

The Harman Kardon One app helps you easily set up the Onyx Studio 9, personalize audio settings, and browse the integrated music services to find your new favorite playlist. You can also customize EQ and control all your compatible speakers in one convenient place.

Technical Specifications

General specifications
• Rated Output power: 50W RMS
• Power supply: 100-240Vac, 50Hz/60Hz

Audio Specification
• Transducers: Woofer 1 x 120mm, Tweeter 3 x 20mm
• Frequency response: 50Hz – 20kHz (-6dB)
• Signal-to-noise ratio: > 80dB

Control and Connection Specifications
• Bluetooth® version: 5.3
• Bluetooth® profile: A2DP 1.4, AVRCP 1.6
• Bluetooth® transmitter frequency range: 2400MHz – 2483.5MHz
• Bluetooth® transmitter power: ≤ 16 dBm (EIRP)
• Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK

Dimension
• Product dimensions (W x H x D): 289.2 x 287.5 x 130 mm / 11.39″ x
11.32″ x 5.12″
• Packaging dimensions (W x H x D): 312 x 322 x 172 mm / 12.28″ x
12.67″ x 6.77″
• Net weight: 3.36kg / 7.42lbs
• Gross weight: 4.2kg / 9.25 lbs

Battery Specifications
• Battery type: Li-ion 17.15 Wh (equivalent to 3.63 V/ 4722 mAh)
• Battery charge time: 4 hours
• Music play time: up to 8 hours (dependent on volume level and
audio content)
• Cable type: AC power cable (type varies by regions)
• Cable length: 2.0 m / 6.6 ft

USB Specifications
Audio playback is for US version only. For other versions, USB is for Service
only.
• USB port: Type C
• USB rating: 5V / 2.1A (Max)
• Supporting file format: mp3

What’s in the box
1 x Harman Kardon Onyx Studio 9
1 x Power Cable
1 x Quick Start Guide
1 x Safety Sheet
